The Power Circuit Diagram: Reading and Building the Supply to the Load

When reading the drawing of a motor control panel, many beginners plunge straight into the control circuit full of buttons and contacts and skip the power circuit diagram — the part drawing the large power lines from the source to the motor. Then when the motor will not run despite a control circuit that "seems right", they are baffled. The problem is often on the power side: a lost phase, a tripped thermal relay, a main contact that will not close. The power diagram and the control diagram are two halves of one system — reading only one half is troubleshooting one half blind.

The power circuit diagram (Japanese: 主回路 — main circuit) describes the large-current path: from the incoming supply, through the protection and switching devices, to the load (a motor, a heating element…). It gathers everything learned in the device articles (#12 contactor, #13 thermal relay, #14 breaker) into an ordered chain. Understanding it is understanding "by what path the power reaches the load and how it is protected".

This article covers the structure of a typical motor power circuit, the order of the devices and why, how to read from source down to load, how it coordinates with the control circuit, and the common power-side faults.

This article states principles. Choosing the devices, the wire cross-section and the protection coordination must follow calculation and the applicable standards for each real load.

The structure of a motor power circuit

Going from source to motor, a typical power circuit has four blocks in order:

Breaker (Q1): protects against a short circuit and serves as the power on/off point (#14).
Contactor main contacts (KM1): switch the motor on the control command (#12).
Thermal relay (F1): protects against overload for the motor (#13).
Motor (M1): the load.

A motor power circuit: three-phase supply through breaker Q1, contactor KM1 main contacts, thermal relay F1, to motor M1

This order is not arbitrary — it reflects the protection logic: the one guarding the most serious and fastest fault (short circuit) stands at the head of the supply; next comes the operational switching device; then the overload protection close to the motor to measure the actual motor current.

Picture it as layers of defence stacked up: the breaker stops the instantaneous disaster (a thousand-amp short circuit), the contactor is the "smart switch" switching on command, the thermal relay watches the smouldering overload most likely to kill the motor. Dropping or reversing any layer leaves a gap: without the breaker a short circuit is not stopped; without the thermal relay the motor burns from an overload the breaker cannot catch (#13, #14 clearly distinguished these two fault types).

Reading the power diagram: from source down to load

Unlike the control circuit read by horizontal rungs (#26), the power circuit is usually drawn with three phases running vertically and read from top (source) down to bottom (load):

At the top: the three-phase supply L1/L2/L3 (and neutral/earth if present).
Going down through each device: each device acts on all three phases (a 3-pole breaker, 3 contactor main contacts, 3 thermal-relay elements).
At the bottom: the motor.

Between each block, the wire number changes (for example 2U/2V/2W after the contactor, U/V/W to the motor) per the numbering rule of #28 — the number changes because it has passed through a device.

The relationship with the control circuit: same-named devices

The spot most confusing to beginners: on the power diagram, KM1 and F1 appear only as main contacts / measuring elements, while the KM1 coil and the F1 signal contact are on the control diagram. They are the same device, in different roles:

The KM1 coil (on the control diagram, the latching circuit of #21) energised → the KM1 main contacts (on the power diagram) close → the motor runs.
The thermal relay F1 measures the current on the power diagram; on an overload, the F1 contact (95-96) on the control diagram opens → cutting the KM1 coil → the motor stops.

So troubleshooting a motor must read both drawings, tracing the device names: check on the control circuit whether the KM1 coil is energised, and on the power circuit whether the main contacts, thermal relay or wiring have a problem.

A classic situation: the KM1 coil is energised (you hear a "click", the indicator lamp lights) but the motor does not turn, or turns weakly and hums. Very likely a KM1 main contact makes poor contact, or a phase is lost on the power circuit → the motor runs on a missing phase and heats up fast. If you look only at the control circuit and see "the coil is energised, so it's fine", you miss this fault entirely. This is why you must always cross-check the two drawings.

Adding blocks by load

The four-block structure is the basic starter; depending on the load you may add:

A semiconductor-protection fuse ahead of a VFD (an ultra-fast fuse).
A VFD/soft starter replacing or standing alongside the contactor when speed control or a smooth start is needed (Stage 7).
Several contactors for reversing (#23) or star-delta (#24).
A current transformer (CT) to measure current for a meter/PLC.
A noise filter, a line reactor for a VFD load.

Whatever is added, the reading principle is still "from source down to load, through the right order of protection and switching".

Load types other than a motor

The motor is the typical load, but the power circuit also serves many other load types, each with its own consideration:

A furnace/heating element: a resistive load, the current has almost no starting peak, choose the contactor per AC-1 (#12). But note that temperature control usually switches very frequently → consider an SSR (#11) instead of a contactor to reduce wear.
A power-factor capacitor: has a very large charging current peak on switching, needs a contactor made for capacitors (with a charge-limiting resistor/reactor).
A transformer: has a magnetising inrush current on switching, choose protection with a suitable curve (type D, #14).
Several small motors on one branch: you must total the current and how each motor is protected.

The general principle: know the load's current characteristic (starting peak, resistive or inductive, switching frequency) then choose the devices and protection curve. The power circuit is only correct when the devices on it suit the load type it serves.

Safety when working on the power circuit

Because it carries a large current and voltage, the power circuit is far more dangerous than the 24V control circuit. A few safety principles following earlier articles:

Isolate the energy before working: cut the power, lock and tag (LOTO), verify it is dead with a meter (per the proper live–dead–live test procedure) before touching.
Mind residual charge: capacitors and VFDs can still be charged after the supply is cut — wait for it to discharge per the guidance.
Do not stand in front of the panel at first energising if you suspect a fault; check carefully beforehand (#39).
Lugs and correct tightening torque: a loose power connection heats up and can cause an arc — a mandatory check item.
Full earthing: the panel enclosure and motor frame earthed for protection to keep people safe on a leakage.

The power circuit is not a place to "test quickly"; the safety discipline here protects lives, not just equipment.

Wire cross-section and protection coordination

The power diagram is tied to wire selection and coordination:

Wire cross-section chosen by the load current and installation conditions; the breaker must protect the wire (#14) — its rated current must not exceed the wire's current-carrying capacity.
Coordination between breaker – contactor – thermal relay per the maker's tables, so that on a short circuit damage is limited (type 1/type 2).
Lugs and tightening torque correct for a large current (#38) — a loose connection on the power circuit causes heat, voltage drop, even fire.

The power circuit carries a large current, so mistakes here have heavier consequences than the control circuit; be careful with the wire, lugs and protection coordination.

A reference engineering scenario

The illustration below is a reference approach in the spirit of MINATA's design thinking; the final ratings and configuration must be confirmed against the actual documentation, standards and equipment.

On a MINATA machine cell, each motor has a power circuit in the exact chain Q → KM → F → M, with wire numbers matching the drawing (#28). The Delta AX-308E output does not switch the contactor coil directly but through an interposing relay (#11); when the KM1 coil closes, the KM1 main contacts on the power circuit supply the motor. The KM1 auxiliary contact and the F1 contact report to the PLC to confirm the state and catch an overload.

When a motor will not run, the MINATA technician reads the two drawings in parallel: the control circuit (is the KM1 coil energised, has F1 tripped) and the power circuit (main contacts, wiring, terminals). Thanks to consistent numbering, tracing the fault is fast and sure — the very value of a good drawing.

Common mistakes

Reading only the control circuit, skipping the power circuit when troubleshooting a motor.
Confusing the main contact (power) with the coil (control) of the same device.
The wrong protection order (placing the thermal relay in the wrong position, missing the breaker).
Choosing a wire with insufficient cross-section for the load current, or a breaker that does not protect the wire.
A loose power connection (missing tightening torque) causing heat and voltage drop.
Not coordinating protection per the maker's tables.
Working on the power circuit before isolating the energy and verifying it is dead.

Power-diagram checklist

[ ] The full chain: source → breaker → contactor → thermal relay → motor.
[ ] Read from source down to load; the wire number changes after each device.
[ ] Trace same-named devices over to the control circuit (coil/signal contact).
[ ] Wire cross-section suited to the current; the breaker protects the wire.
[ ] Protection coordination per the maker's tables; lugs to the right tightening torque.
[ ] Add a VFD/CT/semiconductor fuse when the load requires.
[ ] Choose the devices and curve by the load type's current characteristic (motor, resistive, capacitor, transformer).
[ ] Isolate the energy, verify it is dead, and earth fully before working.
[ ] Mind residual charge in capacitors/VFDs after cutting the supply; wait for full discharge per the guidance.

The power circuit is the "electrical pipeline" bringing energy to the load, and the order of the devices on it is precisely the order of protection. Reading it in parallel with the control circuit — tracing the same-named devices — is what separates a methodical motor troubleshooter from someone who sees only half the picture.
